BassPro SL

Artikelnr. BASSPRO SL
  • Select Color
Product Actions
Add to cart options

Additional Information
Den aktiva BassPro SL får plats under framsätet i de flesta bilar och kompletterar bilstereons fullregisterhögtalare med kraftig bas.
At a Glance:
  • Egenutvecklat baselement med låg profil
  • Effektiv klass D-förstärkare
  • Intelligent elektronisk design
  • Systemkontroll
  • Låg- och högnivåingångar
  • Kan fjärrstyras via kabel
What's in the Box:
  • 1 aktiv baslåda
  • 4 skruvar för montering
  • Bruksanvisning
Den aktiva BassPro SL får plats under framsätet i de flesta bilar och bilstereons fullregisterhögtalare med kraftig bas. Elektroniskt reglage för delningsfrekvens och EQ-inställning gör det enkelt att fintrimma BassPro SL efter din anläggning, bilens akustik och hur du vill att musiken ska låta. Den energieffektiva digitala förstärkaren har kraft nog att driva subwoofern utan att överhettas ens vid hög belastning. BassPro SL ger massor av kraftig bas utan att ta upp mycket utrymme.
Product Features:
  • Egenutvecklat baselement med låg profil
    Det 8 tum (200 mm) stora baselementet i BassPro SL har utvecklats specifikt för att ge låg distorsion och fantastiska basprestanda i en ABS-låda som tar upp anmärkningsvärt lite utrymme.
  • Effektiv klass D-förstärkare
    Förstärkaren som driver BassPro SL producerar minimalt med värme och drar väldigt lite ström från bilens elsystem.
  • Intelligent elektronisk design
    BassPro SL utnyttjar specialkretsar som skydd och för att ge optimala prestanda vid olika volym utan att ljudkvaliteten påverkas.
  • Systemkontroll
    Elektroniskt reglage för delningsfrekvens ger varierbar inställning mellan 50 Hz och 120 Hz så att du kan integrera BassPro SL i bilens ljudanläggning.
  • Låg- och högnivåingångar
    För större flexibilitet vid installation har BassPro SL både lågnivå- och högnivåingångar så att du kan ansluta till både förinstallerade och efterinstallerade anläggningar. Om du använder högnivåingången för att ansluta BassPro SL till huvudenheten finns en belastningsbrytare som växlar mellan "låg" och "hög" för att få ett optimalt ljud.
  • Kan fjärrstyras via kabel
    BassPro SL är kompatibel med RBC Remote Bass Controller (säljs separat) så att du kan fjärrstyra nivån.
Manuals & Downloads:
Allmänna specifikationer:
Amplifier Power
125W RMS
Maximum Current Draw
Quiescent Current Draw
less than 800mA
Input Sensitivity
0.2V – 2V Line-Level Input; 2V – 20V High-Level Input
Audio Specifications:
Frequency Response
35Hz – 120Hz
Crossover Frequency
50Hz – 120Hz
Crossover Slope
Bass Boost
0dB to +9dB @ 70Hz
9-7/8"; (250mm)
13-9/16"; (344mm)
Woofer Specifications:
8"; (200mm)
BassPro SL is rated 4.8 out of 5 by 46.
Rated 5 out of 5 by from Great sound Hi. I bought the Baspro SL few days ago, I just mount it last Saturday. My car is a sedan, the SL is mounted under the passenger seat. First, I had the impression the base is not loud and clear, I was almost disappointed. But... Then... Surprise! It sounds just great. Is all you need if you don't want to destroy your ears or to play music for the people outside the car. So, I strongly recommend this product, is just awesome and all you need for a loud and clear base in your car. Of course, now I have to change my speakers also, because the Basspro SL is to strong and the original speakers can't handle it :)
Date published: 2017-08-22
Rated 5 out of 5 by from Great Sound, great Value Bought A couple days ago, honestly didn't expect much bass out of it. But it really suprised me. Really great bass, it's very accurate, took me a couple days to get the sound I wanted from it but from tuning my stereo and speaker it sounds fenomenal. It's really worth the price just need to fine tune it to your taste. I have 07 Tacoma with the JBL system so switching OE Head unit and throwing one of these in there makes a really good combination. Also very easy to install and doesn't need much wire since it right under my seat. Overall great product. And loss of space
Date published: 2016-12-14
Rated 5 out of 5 by from Perfect Clean Bass in compact package I installed this under the passenger seat of My minivan about a month ago and I am impressed. The installation required me to raise it so that it fit above the underseat vents, but it still fit just fine. This little sub is EXACTLY what I was looking for, small hidden and permanent with excellent sound ( i do not like removing subs when I need space for cargo) I have heard better subs, but they are 20 times the size of this and cost more than twice as much. This Sub was not designed to wake up the neighborhood, but you cant beat the BassPro SL for moderate bass enhancement and clarity.
Date published: 2017-08-07
Rated 5 out of 5 by from Just The Job I replaced the factory sub in my UK spec 2013 Honda CRV EX with this and am so glad i did. Huge upgrade over the so called ''premium'' audio system fitted by the manufacturer. Fits neatly under the front passenger seat, very easy to fit, and lots of adjustment to give you the sound you require. Gives you more than just bass, seems to lift the whole system sound quality. I've also replaced the factory door speakers with JBL GT6 series speakers and now the whole system sounds great. Plenty of punch and lots of detail as well. Highly recommended.
Date published: 2017-12-11
Rated 5 out of 5 by from Just right At first I wasn't impressed after the initial install. All of their experience was with a competitor's hideaway sub. Two weeks later a different tech tweaked the gain and cross over and the JBL came alive. What a sub. Mind you, it does distort a little if the volume is maxed out on extremely low and pronounced bass, but overall this sub does what it is made to do. My head unit is stock. Also, for the first month or so it was just the 6 in door speakers from JBL w/o the sub, so it was real disappointing with the sub until the settings were adjusted.
Date published: 2018-03-10
Rated 4 out of 5 by from Better than expected, you should really buy two! I just bought one for under the drivers seat in a Jeep Wrangler 4-door as part of a total JBL speaker upgrade from the factory basic sound system. This is great in a vehicle like a Jeep Wrangler where you want good sound but don't want a big subwoofer enclosure that will get stolen when the roof and doors are off. I didn't have high expectations due to its small form factor but it is a definite improvement in the low end response. It keeps up volume-wise fairly well with the amp built into my Pioneer AVH-4100NEX head unit (14w x 4). Having one under each front seat would definitely be ideal. Bass response below 40Hz is extremely limited, there is a steep low-end roll off but that allows for higher output volume without destroying the small 8" woofer.
Date published: 2016-02-01
Rated 5 out of 5 by from Fantastisk lille plastik kasse!!! Man kan selvfølgelig få meget mere bund-bass i bilen hvis det er det man ønsker. Men hvis man gerne vil bruge sit bagagerum til bagage:) og man søger noget der er billigt i forhold til ydelse, og let at montere. Så kan du roligt anskaffe dig en basspro sub. den har Mange indstillings muligheder og Rigtig god lyd(som kan mærkes).. jeg har en C5 III Tourer med cigaretstik i bagagerummet, i stikket har du både en plus og minus pol. Så har jeg slagtet en 1000w camping elkedel(til bil med cigaretstik) og sat ledningen til sub'en. Bilen har integreret lydsystem( ingen sub udgang) så sub'en er tilsluttet over de normale højtalere i dørene. Virker fint, lyder godt. JBL har sgu gjort det igen:)
Date published: 2017-09-29
Rated 5 out of 5 by from Deep bass Regular cab pickup have 2,one under each seat. Bass is deep and can feel it. Adjustments on stereo head unit are critical. Have 45 watt per channel amp for other JBL speakers,GTOs and CLUBs. This is blendable easily. Does not disturb useful space. They fit nicely. Have nice look also,but nobody sees them : )
Date published: 2018-06-02
  • y_2018, m_11, d_13, h_5
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.8
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_46
  • loc_sv_SE, sid_bassprosl, prod, sort_[SortEntry(order=RELEVANCE, direction=DESCENDING)]
  • clientName_harmanaudio

Is this JBL BassPro SL fit to my Suzuki Baleno 2018?

Asked by: Orlando Herrera
We don't have a direct answer to that but feel free to check the space on your Suzuki Baleno as the BassPro SL's Dimensions are (L x W x H): 13-9/16" x 9-7/8" x 2-13/16" (344mm x 250mm x 71mm) . If you have a free space of the said dimension then it should be good enough.
Answered by: Mario at Customer Service
Date published: 2018-10-22

Will the JBL BassPro SL work with the stock head unit on my 2013 Toyota Corolla? And will the speakers fit under the front seats of that vehicle?

Asked by: gartneraz
We would like to work with you directly. Please submit a case request at https://www.jbl.com/support-contact.html and the Customer Service Team will be more than happy to assist you.
Answered by: Rhae
Date published: 2018-09-25

does this refurbished unit come with the instructions , wire connectors, harness ?

Asked by: larry teknus
Yes, it includes those components.
Answered by: Steve S
Date published: 2018-09-12

hello, can the other car speakers be connected to the subwoofer to amplify them?

Asked by: kiiko1993
We would like to work with you directly to help you with your issue. Please submit a case request at https://www.jbl.com/support-contact.html and the Customer Service Team will be more than happy to assist you.
Answered by: Mario at Customer service
Date published: 2018-08-18

Does this fit a SmartCar 2013 Pure?

Asked by: jimthe3
Unfortunately, we do not have any information on this vehicle, so we are unable to say whether or not the BassPro SL would fit your car.
Answered by: Steven M
Date published: 2018-06-04

I have a 2016 GMC Sierra With the Bose speakers, Will this cause a problem from the system if I add the Subwoofer to it

Asked by: barnesqw45
No it will not negatively effect anything. If you just have a properly trained technician catch the sign and turn on lead from the correct outputs. All should be good when done correctly. Most MECP TECHS are more than capable.
Answered by: 22 year technician
Date published: 2018-07-11

I am trying to dedicate the High & Mid Frequencies to my factory speakers, and use the BassPro SL to just process the Low Frequencies. Can I do this by adjusting the settings on the Sub or would a line out converter help separate the signals?

Asked by: JY00
We would like to work with you directly to help with your inquiry. Please submit a case request at https://www.jbl.com/support-contact.html and the Customer Service Team will be more than happy to assist you.
Answered by: Gian at Customer Service
Date published: 2018-06-07

Zitten er ook kabels, om de subwoofer aan te sluiten, in de verpakking. Of is dit enkel de powered subwoofer zonder bekabeling. Indien er kabels meegeleverd zijn, welke kabels zijn dit precies?

Asked by: SjoerdBos2
Hi Sjoerd, Bij de BassPro SL worden geen kabels meegeleverd.
Answered by: Kay Harman
Date published: 2018-09-07
